GENERAL PRODUCT INFORMATION
Type
Sheet Fed Type Network Scanner
Scanning sensor unit
CMOS CIS 1 Line Sensor
Optical resolution
600dpi
Light source
RGB LED
Scanning side
Front / Back / Duplex
Interface
LAN 10BaseT/100BaseTX Connector
Hi-Speed USB 2.0 x 4 (for Mouse & Keyboard)
Dimensions (WxDxH)
Tray closed: 310 (W) x 161 (D) x 215 (H) mm
-
Tray opened: 310 (W) x 298 (D) x 571 (H) mm
Weight
Approx. 3.5kg
Power requirements
AC200 - 240V (50/60Hz)
Power consumption
Scanning: 29W
Standby power saving
18.6W or less (network port connected)¹
Standby delay time
12 minutes (display turns off)
Operating environment
10 - 32.5°C (50 - 90.5°F), Humidity: 20 - 80% RH
SCANNING SPEED (200DPI)
Black and White
26ppm / 40ipm
Colour
18ppm / 17ipm
Output resolution
100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi
Output mode
B&W / Error Diffusion / Advanced Text Enhancement, 8bit (256 level) Greyscale, 24bit colour
Daily duty cyle
Approx. 3000 scans/day
NETWORK FEATURES
Operation panel (controller)
8.4inch SVGA Liquid Crystal Display with Touch Panel
Fingerprint Authentication
Optical Sweep Type Sensor (ScanFront 300eP only)
DOCUMENT SPECIFICATIONS
Width
50.8 - 216mm
Length
53.9 - 355.6mm
Thickness
Automatic Feeding: 52 - 209g/m2 (0.06 - 0.25mm)
Bypass Mode: 40 - 209g/m2 (0.05 - 0.25mm)
Long document mode
Maximum: Legal = 355.6mm
Card scanning
Width: 53.9mm, Length: 85.5mm, Thickness: 0.76mm
(Cards with embossed letter are supported)
Paper separation
Retard Roller (Reversing Separator Roller)
Feeder capacity
50 sheets (80 g/m²)
SPECIAL FEATURES
-
Auto Size Detection / Deskew / Text Orientation Recognition /
Prevent Bleed Through & Remove Background
Skip Blank Page / Color Drop Out, Enhance (RGB only)
Image Rotation / Inverse / Mirror / Scaling, Fingerprint sensor (SF300eP only),Ultrasonic Double Feed Detection (SF300eP only)
Bypass Feeding
SOFTWARE
Sending Functions
Scan to File (Folder/FTP/USB memory), Scan to Printer, Scan to Mail/Fax (via SMTP/Microsoft Exchange/
Lotus Notes), Scan to WebDAV, Scan to Database
Available functions vary depending on the license provided with your ShareScan Package.
eCopy ShareScan Options
eCopy ShareScan Elements,
eCopy ShareScan Office,
eCopy ShareScan Suite
Connectors & Extenders
For latest information about ShareScan Connectors Extenders & other available 3rd party connectors please visit the Nuance website here -
http://www.nuance.com/for-business/by-product/ecopy/ecopy-connectors-and-extenders
eCopy ShareScan server PC requirements
O/S: Microsoft Windows XP Pro (SP3 or later), Vista Business or Enterprise Edition SP1 or later, Windows 2003 Server, Windows 2008 Server, Windows 7 Business /Ultimate
Support OS:
Windows XP Professional 32bit
Windows Server 2003 R2 32bit and 64 bit
Windows Vista Business/Enterprise 32 bit
Windows Server 2008 R2
Windows 7 Business / Ultimate
General office use:
Pentium4 2.4 GHz with Hyper-Threading
RAM:1 GB(recommended)
RAM:512 MB(at least).
Light production scanning:
Dual processor P4 3.2 GHz with Hyper-Threading
RAM:1 GB(at least)
Heavy production scanning:
Dual processor Xeon
RAM:1 GB (at least)
Disclaimer
All data is based on Canon standard testing methods except where indicated.
Subject to change without notice
Footnote
¹ This product is intended for desktop style thin clients, it does not comply with limits on power consumption established in Lot 26.
Canon
