PRINTER SPECIFICATIONS
Print Technology
Inkjet with FINE print head technology
Image Input
RGB (sRGB/AdobeRGB)
Print Resolution
2400 x 1200 dpi
Printing Size
89 x 89 mm - 635 x 305 mm
Printing Speed (approx.)
A4 (210 x 297 mm) double-sided: 1000 pages per hour ¹
A4 (210mm x 297mm) single-sided: 1140 pages per hour ¹
635 x 305 mm (25 x 12") single-sided: 380 pages per hour ¹
457 x 305 mm (18 x 12") single-sided: 525 pages per hour ¹
102 x 152mm (4 x 6") single-sided: 2330 pages per hour ¹
INK SYSTEM
Inks
Seven colours:
Black, Cyan, Magenta, Yellow, Photo Cyan, Photo Magenta, Grey
Type
Dye-based inks
PAPER HANDLING
Supported Paper Types
Glossy type (single-sided) 275 gsm
Glossy type (double-sided) 250 gsm
Satin type (double-sided) 165 gsm
Luster type (single-sided) 200 gsm
Luster type (single-sided) 266 gsm
Luster type (double-sided) 230 gsm
Silky type (single-sided) 185 gsm
Metallic silky type (single-sided) 198 gsm
Paper Supply
Two rolls loadable as standard
Four rolls loadable with optional paper deck
Paper Sorter
Large-size 10 bins
Small-size 10 bins
DIMENSIONS AND WEIGHT
Dimensions (W x D x H)
3630 x 1600 x 1540 mm
4325 x 1600 x 1540 mm (with optional paper deck)
Weight
Max. 2640 kg ¹
Max. 2900 kg (with optional paper deck) ¹
OPERATING INFORMATION
Operating Environments
Temperature: 15 - 27 °C
Humidity: 30 - 70 %
Power Requirements
Three-phase 380/400/415V 30A 50Hz x 2
Single-phase 220-240V 30A 50Hz x 1
Power Consumption
Printing: Approx. 5500Wh
Off: Approx. 50Wh
Noise Level
70 db(A)
Required Space (W x D x H)
6292 x 3829 x 2090 mm
6987 x 3829 x 2090 mm (with optional paper deck)
Disclaimer
All specifications are subject to change without notice.
See brochure for full paper support information.
This product is for printing purposes only. For photo album production, a book binding process would be necessary with additional equipment.
All specifications are subject to change without notice.
See brochure for full paper support information.
This product is for printing purposes only. For photo album production, a book binding process would be necessary with additional equipment.
All specifications are subject to change without notice.
See brochure for full paper support information.
This product is for printing purposes only. For photo album production, a book binding process would be necessary with additional equipment.
Footnote
¹ The productivity values are measured using Canon's measurement method.
¹ Maximum weights includes: 7 ink tanks, 7 print heads, 2 or 4 rolls of paper, the back side printer, a wirehead, an ink ribbon, waste ink, humidifying water, and coolant. Floor plates not included.
¹ The productivity values are measured using Canon's measurement method.
¹ Maximum weights includes: 7 ink tanks, 7 print heads, 2 or 4 rolls of paper, the back side printer, a wirehead, an ink ribbon, waste ink, humidifying water, and coolant. Floor plates not included.
¹ The productivity values are measured using Canon's measurement method.
¹ Maximum weights includes: 7 ink tanks, 7 print heads, 2 or 4 rolls of paper, the back side printer, a wirehead, an ink ribbon, waste ink, humidifying water, and coolant. Floor plates not included.
