GENERAL SPECIFICATIONS
Functions
Wi-Fi, Print, Copy, Scan, Cloud
OVERVIEW
PRINTER SPECIFICATIONS
Print Resolution
Up to 4800¹ x 600 dpi
Print Technology
2 FINE Cartridges (Black and Colour)
Inkjet system with 2pl (min.) ink droplet size
Mono Print Speed
Approx. 8.0 ipm¹
Colour Print Speed
Approx. 4.0 ipm¹
Borderless Printing
Not available
Two Sided Printing
Manual operation
CARTRIDGES AND YIELDS
Standard Ink Cartridges
PG-545 (Black)
CL-546 (Colour)
Optional XL Ink Cartridges
PG-545XL (Black)
CL-546XL (Colour)
Cartridge Yield (Plain paper)
A4 colour documents printing¹
Black: 180 pages
Black XL: 400 pages
Colour: 180 pages
Colour XL: 300 pages
Paper Types
Plain Paper
Envelopes
Photo Paper Plus Glossy II (PP-201)
Photo Paper Glossy "Everyday Use" (GP-501)
Maximum Paper Input
Rear tray: Max. 60 sheets (plain paper)
Paper Sizes
Plain paper: A4, A5, B5, Letter, Legal
Photo paper: 10x15cm, 13x18cm
Envelopes: DL, COM10
Paper Weight
Plain paper: 64 - 105 g/m²
Canon photo paper: up to 275 g/m²
Scanner Type
CIS flatbed photo and document scanner
Scanner Resolution (Optical)
600 x 1200 dpi¹
A4 Scan Speed
Approx. 14 sec¹
Scanning Depth (Input / Output)
Colour: 48 bit / 24 bit
Greyscale: 16 bit / 8 bit
Maximum Document Size
216 x 297 mm
Copy Speed
sFCOT: Approx. 31 sec¹
sESAT: Approx. 1.6 ipm¹
Multiple Copy
21 copies (max.)
Copy Functions
Document copying (plain paper)
Document Size
Max. copy area of approx. 203 x 277mm
(A4 with a 17mm bottom print margin)
Interface Type - PC / Mac
Hi-Speed USB (B Port)
Wi-Fi: IEEE802.11 b/g/n
Wi-Fi Security: WPA-PSK, WPA2-PSK, WEP, Administration password
Wireless LAN Frequency Band: 2.4GHz
Please refer to the user manual for instructions on how to activate/deactivate the wireless LAN.
Interface Type - Other
PIXMA Cloud Link
Canon PRINT app
Canon Print Service Plugin (Android)
Google Cloud Print
Access point mode
PictBridge (WLAN)
Supported Operating Systems
Windows 10 / 8.1 / 8 / 7 / Vista SP1 & SP2 / XP SP3 32-bit
Mac OS X v10.6.8 or later
Supported Mobile Systems
iOS
Android
Windows RT
Minimum System Requirements
Windows: 3GB disk space, Internet Explorer 8
Mac: Internet connection, 1.5GB disk space, Safari 5
Display: 1024 x 768 XGA
Software Included
MP Driver including Scanning Utility
My Image Garden with Full HD Movie Print¹
Quick Menu
Easy-WebPrint EX (download)²
Weight
Approx. 3.5 kg
Dimensions (W x D x H)
426 x 306 x 145mm
Acoustic Noise Levels
Approx. 46.5 dB¹
Recommended Operating Environment
Temperature: 15-30°C
Humidity: 10-80%RH (no dew condensation)
Power Source
AC 100-240V, 50/60Hz
Power Consumption
Off: Approx. 0.3 W
Standby (Wirelelss LAN connection to PC): Approx. 1.6 W (scanning lamp off)
Standby (all ports connected): Approx. 1.6 W (scanning lamp off)
Time to enter Standby mode: 7 minutes
Copying: Approx. 11 W¹
Disclaimer
All specifications subject to change without notice.
Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
Ink yield may vary depending on texts/photos printed, applications software used, print mode and type of paper used. For yield information see www.canon-europe.com/ink/yield
Scan speed may vary depending on system configuration, interface, software, scan mode settings and document size etc.
Copy speed may vary depending on document complexity, copy mode, page coverage, type of paper used etc. and does not take into account warming up time.
All brand and product names are trademarks of their respective companies.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.
All specifications subject to change without notice.
Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
Ink yield may vary depending on texts/photos printed, applications software used, print mode and type of paper used. For yield information see www.canon-europe.com/ink/yield
Scan speed may vary depending on system configuration, interface, software, scan mode settings and document size etc.
Copy speed may vary depending on document complexity, copy mode, page coverage, type of paper used etc. and does not take into account warming up time.
All brand and product names are trademarks of their respective companies.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.
Footnote
¹ Ink droplets can be placed with a minimum pitch of 1/4800 inch
¹ A4 document print speed on plain paper is measured based on average of ESAT in Office Category Test of ISO/IEC 24734 standard.
¹ A4 document print speed on plain paper is measured based on average of ESAT in Office Category Test of ISO/IEC 24734 standard.
¹ Declared yield value in accordance with ISO/IEC 24711 standard. Values obtained by continuous printing.
¹ Colour document scan speed is measured with ISO/IEC 24735 Annex C Test Chart A. Scan speed indicates the time measured between pressing the scan button of the scanner driver and the on-screen status display turns off.
¹ Optical resolution is a measure of maximum hardware sampling resolution based on ISO 14473 standard. When scanning in high resolution, the maximum scan size is restricted.
¹ Colour document copy speed is measured based on average of sFCOT and sESAT in Performance Test of ISO/IEC 29183 standard.
¹ Full HD Movie Print is available for MOV and MP4 movie files created by select Canon digital cameras and camcorders. Requires installation of software bundled with Canon video or digital camera, from which the movie was captured. MOV files require: ZoomBrowser EX / ImageBrowser (version 6.5 or later), MP4 files require: ImageBrowser EX (version 1.0 or later).
² Easy-WebPrint EX requires Internet Explorer 8 or later
¹ When copying ISO/JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings.
¹ When printing ISO/JIS-SCID N2 pattern on 10x15cm Photo Paper Plus Glossy II using default settings.
¹ Ink droplets can be placed with a minimum pitch of 1/4800 inch
¹ A4 document print speed on plain paper is measured based on average of ESAT in Office Category Test of ISO/IEC 24734 standard.
¹ A4 document print speed on plain paper is measured based on average of ESAT in Office Category Test of ISO/IEC 24734 standard.
¹ Declared yield value in accordance with ISO/IEC 24711 standard. Values obtained by continuous printing.
¹ Colour document scan speed is measured with ISO/IEC 24735 Annex C Test Chart A. Scan speed indicates the time measured between pressing the scan button of the scanner driver and the on-screen status display turns off.
¹ Optical resolution is a measure of maximum hardware sampling resolution based on ISO 14473 standard. When scanning in high resolution, the maximum scan size is restricted.
¹ Colour document copy speed is measured based on average of sFCOT and sESAT in Performance Test of ISO/IEC 29183 standard.
¹ Full HD Movie Print is available for MOV and MP4 movie files created by select Canon digital cameras and camcorders. Requires installation of software bundled with Canon video or digital camera, from which the movie was captured. MOV files require: ZoomBrowser EX / ImageBrowser (version 6.5 or later), MP4 files require: ImageBrowser EX (version 1.0 or later).
² Easy-WebPrint EX requires Internet Explorer 8 or later
¹ When copying ISO/JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings.
¹ When printing ISO/JIS-SCID N2 pattern on 10x15cm Photo Paper Plus Glossy II using default settings.
