BASIC SPECIFICATIONS
Machine Type
Black and White Laser Multifunctional
Available Core functions
Print, Copy, Scan, Send and Fax
PRINT SPEED (BW)
Print speed (BW/CL)
A4: 25 ppm (iR3025Ne), 45 ppm (iR3045Ne)
A3: 14 ppm (iR3025Ne), 22 ppm (iR3045Ne)
A4R: 17-14 ppm (iR3025Ne); 20-16 ppm (iR3045Ne)*
A5R: 17-14 ppm (iR3025Ne); 20-16 ppm (iR3045Ne)*
*Adjustments for machine temperature or image quality may cause machine operations to pause or become slow when used continuously.
Printing Method
Laser Beam Printing
Print resolution
600 dpi x 600 dpi, 2400 dpi x 600 dpi (enhanced)
Double sided printing
Automatic (Standard)
Printing from memory media
N/A
Support for mobile and cloud printing
Canon Mobile Printing: support for printing from iPAD/iPhone (iOS) and Android devices.
Please, contact your Canon representative for further information.
Paper input (Standard)
Paper cassettes: 4 x 550 sheets (80 gsm)
Multi-purpose tray: 50 sheets
PAPER INPUT (OPTION)
Maximum paper input capacity
2250 sheets (80 gsm)
Paper output capacity
Inner Finisher with 1 Tray: 1000 sheets (A4, 80 gsm)
Finishing capabilities
Collate, Group, Staple (Corner only)
Supported media types
Cassettes:
Plain, Recycled, Colour, Pre-punched
Multi-purpose tray:
Plain, Recycled, Colour, Pre-punched, Heavy (90-128 gsm), Transparency, Labels, Envelopes
Supported media sizes
Paper cassette 1: A4, A4R, A5R
Paper cassette 2, 3 and 4: A3, A4, A4R, A5R
Multi-purpose tray: A4, A4R, A3, A5R, Free size: 99 mm x 140 mm to 320 mm x 457 mm
Envelopes: No.10 (COM10), Monarch, ISO-C5, DL
Supported media weights
Paper cassettes: 64 to 90 gsm
Multi-purpose tray: 64 to 128 gsm
Duplex: 64 to 105 gsm
Page Description Language(s)
UFRII/PCL5/6 (Standard)
PostScript Level 3 Emulation (Optional)
Fonts
PCL fonts: 80 Roman, 1 Bitmap,
PS fonts: 136 Roman fonts
Operating System compatibility
UFRII: Windows XP/Server 2003/Vista/Server 2008/Windows 7/Server 2008 R2/Windows 8, MAC OS x (10.5.x or later)
PCL: Windows XP/Server 2003/Vista/Server 2008/Windows 7/Server 2008 R2/Windows 8
PS: Windows XP/Server 2003/Vista/Server 2008/Windows 7/Server 2008 R2/Windows 8, MAC OS x (10.5.x or later)
PPD: MAC OS 9.1 or later, MAC OS X (10.3.9 or later), Windows XP/Server 2000/Windows 7/Windows 8
Please refer to http://software.canon-europe.com/ for availability of print solutions for other operating systems and environments including AS/400, UNIX, Linux and Citrix. Some of these solutions are chargeable.
SAP Device Types are available via the SAP Market Place.
COPY SPECIFICATIONS
Copy speed
A4: 25 ppm (iR3025Ne), 45 ppm (iR3045Ne)
A3: 14 ppm (iR3025Ne), 22 ppm (iR3045Ne)
A4R: 17-14 ppm (iR3025Ne); 20-16 ppm (iR3045Ne)*
A5R: 17-14 ppm (iR3025Ne); 20-16 ppm (iR3045Ne)*
*Adjustments for machine temperature or image quality may cause machine operations to pause or become slow when used continuously.
First Copy Output Time (FCOT)
Approx. 4.9 sec or less (iR3025Ne), 3.9 sec or less (iR3045Ne)
Copy resolution
Reading: 600 dpi x 600 dpi
Copying: 1200 dpi x 600 dpi (enhanced)
Multiple copy
Up to 999 copies
Reduction/Enlargement
Zoom: 25-400 % in 1 % increments
Fixed Zoom Ratio: 25 %, 50 %, 71 %, 100 %, 141 %, 200 %, 400 %
SCAN SPECIFICATIONS
Optional/Standard
A standard IMAGE READER UNIT provides:
Flatbed scan unit and a 50-sheet duplex automatic document feeder (DADF).
SUPPORTED MEDIA SIZE/S
Supported media sizes
A3, A4, A4R, A5, A5R;
Free sizes (W x L): Min. 128 mm x 148 mm, Max. 297.4 mm x 431.8 mm
SUPPORTED MEDIA WEIGHT/S
Supported media weights
Single-sided scanning: 42 to 128 gsm
Double-sided scanning: 50 to 128 gsm
Scan resolution
100 dpi, 150 dpi, 200 dpi x 100 dpi, 200 dpi, 300 dpi, 200 dpi x 400 dpi, 400 dpi, 600 dpi
Double sided scanning
2-sided to 2-sided (Automatic)
Scan speed
Single-sided:
45 ipm (BW, 600 dpi);
45 ipm (BW, 300 dpi)
Double-sided:
15 ipm (BW, 600 dpi);
15 ipm (BW, 300 dpi)
Scan methods
Push Scan: Send functionality standard,
Pull Scan: TWAIN/WIA Pull scanning,
Scan to USB Memory Key: not supported
Pull scan specifications
TWAIN via Network TWAIN Driver (Colour Network ScanGear):
Supported OS: Windows 2000/Windows XP/Windows Server 2003/Windows Vista/Windows Server 2008/Windows 7/Windows 8 (32 bit, 64 bit in compatibility mode)*
WIA via Network WIA Driver:
Supported OS: Windows Vista/Windows Server 2008/Windows 7/Windows 8 (32 bit, 64 bit)*
*The drivers are available via http://software.canon-europe.com/
SEND SPECIFICATIONS
Optional/Standard
Standard
Send resolution
100 dpi, 150 dpi, 200 dpi x 100 dpi, 200 dpi, 300 dpi, 200 dpi x 400 dpi, 400 dpi, 600 dpi
Destinations
E-Mail/Internet FAX (SMTP), PC (SMB, FTP)
Address Book/Speed dials
LDAP (1000)/Local (Max. 1800)
File formats
TIFF, PDF
Optional Universal Send Feature Sets
UNIVERSAL SEND SEARCHABLE PDF KIT-A1: Enables searchable PDF (OCR).
UNIVERSAL SEND PDF SECURITY FEATURE SET-A1: Adds encrypted PDF and device signature PDF.
DIGITAL USER SIGNATURE PDF KIT-A1: Enables attaching user electronic signature on PDF.
FAX SPECIFICATIONS
Optional/Standard
Standard
Modem speed
Super G3 33.6 kbps (Up to 3 sec/page ¹)
Fax Resolution
Standard: 200 x 100 dpi
Fine: 200 x 200 dpi
Super fine: 200 x 400 dpi
Ultra fine: 400 x 400 dpi
FAX memory
Up to 3700 pages ¹
Speed dials
Max. 200
Group dials/destinations
Max. 199 dials
Sequential broadcast
Max. 256 addresses from the address book plus new 256 destinations
Memory backup
HDD
Other features
Fax Forwarding, Dual Access, PC Fax (TX only)
GENERAL SPECIFICATIONS
Warm-up time
Approx. 30 sec from power ON
Recovery from sleep mode
15 sec
Interface type
USB 2.0 Hi-Speed; Ethernet: 100Base-TX/10Base-T
Network protocols
TCP/IP (LPD/Port9100/IPP/IPPS/SMB/FTP), IPv6, IPX/SPX (NDS, Bindery), AppleTalk
*IPv4/IPv6 support
Processor speed
300MHz (Uses Main unit CPU)
Memory
512 MB
Hard Disk drive
20 GB
Control panel
19 cm (7.5 inch) VGA Colour LCD Touch Panel
Dimensions (W x D x H)
565 mm x 700 mm x 1135 mm
Installation space (W x D)
862 mm x 1158 mm (when multi-purpose tray is extended + cassette drawers open)
Weight
Approx. 106 kg
Operating environment
Temperature: 15 to 27.5ºC (59 to 81.5 ºF)
Humidity: 25 to 75 % RH (no condensation)
Power source
AC 220-240 V (±10 %), 50/60 Hz (±2 Hz)
Power consumption
Maximum: Approx. 1.35 KW
Standby: Approx. 39 W
Sleep mode: Approx. 1 W or less ¹
Typical Electricity Consumption (TEC) rating ²: 8.397 kwh
Noise levels
Sound Pressure ¹
Active: 61.3 dB (iR3025Ne), 65.2 dB (iR3045Ne)
Standby: Inaudible
Software and printer management
iW Management Console for centralised management of the device (Consumables and error monitoring and alerts);
Compatible with eMaintenance services via embedded RDS (Enables meter capture, automatic consumables management and remote diagnostics);
Canon Driver Configuration Tool; Remote User Interface (RUI); Network ScanGear; MEAP (Multifunctional Embedded Application Platform)
Security features
Standard:
IP/Mac Address Filtering, SSL, Secure Print, Data Erase, SSOH, Department ID, Mailbox
Optional:
Hard disk encryption, secure watermark, device and user signatures, encrypted PDF
TONER BOTTLE
Toner Cartridge/s
C-EXV 11 TONER BK (yield 21000) ¹ (for iR3025Ne);
C-EXV 12 TONER BK (yield 24000) ¹ (for iR3045Ne)
SPECIFICATIONS FOR OPTIONS
Staple/Booklet Finisher 1
FINISHER-S1 (compact inner finisher) (Standard)
Number of Trays: 1
Standard Tray Capacity: 1000 sheets (A4/A5/A5R), 500 sheets (A3, A4R) (80 gsm)
Paper Weight: 64 to 128 gsm
Staple Position: Corner
Staple Capacity: A4: 50 sheets; A3/A4R: 30 sheets
Staple/Booklet Finisher 2
N/A
HARDWARE ACCESSORIES
Print controller accessories
PS PRINTER KIT-S1: Enables PostScript printing.
BARCODE PRINTER KIT-D1: Enables barcode printing via jet caps technology.
Document Publishing
iW DESKTOP: Powerful print publishing software which easily combines documents from different sources, applies finishing to create professional looking documents and seamlessly links to the printer. Includes PDF creation, annotation and compression capabilities for digital workflows such as proofing and authorization.
SYSTEM ACCESSORIES
Device security accessories
HDD DATA ENCRYPTION KIT-B4: Encrypts all image data and device settings before storing them on the hard drive of the device.
DOCUMENT SECURITY ACCESSORIES
Accessibility accessories
REMOTE OPERATORS SOFTWARE KIT-B1: Allows use of the device control panel screens from remote computers.
Other options
Staple CRG-J1 GP
Disclaimer
All specifications subject to change without notice
All specifications subject to change without notice
Footnote
¹ Based on ITU-T Standard Chart No. 1.
¹ Based on ITU-T Standard Chart No. 1.
¹ The quoted sleep mode consumption may not be possible in all circumstances. Certain network configurations and options may prevent the device from entering deep sleep mode. Please refer to the user guide for more information.
² Typical Electricity Consumption (TEC) rating represents the typical electricity consumed by a product during 1 week, measured in kilowatt-hours (kWh). The test methodology is defined by Energy Star (http://www.eu-energystar.org).
¹ Declared noise emission in accordance with ISO 7779.
¹ Based on 6% coverage.
¹ Based on ITU-T Standard Chart No. 1.
¹ Based on ITU-T Standard Chart No. 1.
¹ The quoted sleep mode consumption may not be possible in all circumstances. Certain network configurations and options may prevent the device from entering deep sleep mode. Please refer to the user guide for more information.
² Typical Electricity Consumption (TEC) rating represents the typical electricity consumed by a product during 1 week, measured in kilowatt-hours (kWh). The test methodology is defined by Energy Star (http://www.eu-energystar.org).
¹ Declared noise emission in accordance with ISO 7779.
¹ Based on 6% coverage.
