DSLR Cameras
Canon EOS 760D
Specifications0 – 40 °C, 85% or less humidity
Approx. 131.9 x 100.9 x 77.8 mm
Approx. 565g (CIPA testing standard, including battery and memory card)
22.3 x 14.9mm CMOS
Approx. 24.2 megapixels
Approx. 24.7 megapixels
3:2
Built-in/Fixed
EOS integrated cleaning system
Primary Colour
DIGIC 6
EF/EF-S
Equivalent to 1.6x the focal length of the lens
TTL-CT-SIR with a CMOS sensor
19 cross-type AF points (f/2.8 at centre)
EV -0.5 -18 (at 23°C & ISO100)
AI Focus
One Shot
AI Servo
Automatic selection: 19 point AF
Manual selection: Single point AF
Manual selection: Zone AF
Indicated by a transmissive LCD in viewfinder and on top LCD panel and Quick Control screen
Locked when shutter button is pressed half way in One Shot AF mode.
Intermittent firing of built-in flash or emitted by optional dedicated Speedlite
Selected on lens
7560-pixel RGB+IR metering sensor
Metering with the area divided into 63 segments (9×7)
(1) Evaluative metering (linked to all AF points)
(2) Partial metering (approx. 6.0% of viewfinder)
(3) Spot metering (approx. 3.5% of viewfinder)
(4) Center-weighted average metering
EV 1-20 (at 23°C with 50mm f/1.4 lens ISO100)
Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE lock button in creative zone modes.
'+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).
'3 shots +/- 2 EV, 1/2 or 1/3-stop increments
Recommended Exposure Index
AUTO(100-6400), 100-12800 in 1-stop increments
ISO can be expanded to H: 25600
During Movie shooting: Auto (100-6400), 100-6400 (Whole stop increments) ISO can be expanded to H: 12800
Electronically-controlled focal-plane shutter
30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
Auto white balance with the imaging sensor
AWB, Daylight, Shade, Cloudy, Tungsten, White
Fluorescent light, Flash, Custom.
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/ Green +/-9.
Yes, 1 setting can be registered
'+/-3 levels in single level increments
3 bracketed images per shutter release.
Selectable Blue/Amber bias or Magenta/Green bias.
Pentamirror
Approx. 95%
Approx. 0.82x¹
Approx. 19mm (from eyepiece lens centre)
'-3 to +1 m-1 (dioptre)
AF information: AF points, focus confirmation light
Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, spot metering circle, exposure warning, AEB
Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light
Image information: Highlight tone priority (D+), monochrome shooting, maximum burst (1 digit display), White balance correction, SD card information, Flicker Detection, focus area, electronic level
Yes, with Depth of Field preview button.
On strap
Touch screen vari angle 7.7cm (3.0") 3:2 Clear View II TFT, approx. 1040K dots
Approx. 100%
Approx. 170°
Solid Structure and Anti smudge
Adjustable to one of seven levels
(1) Quick Control Screen
(2) Camera settings
(3) Dual Axis Electronic Level
'12
up to 17mm focal length (35mm equivalent: 28mm)
Approx. 3 seconds
Auto, Manual flash, Integrated Speedlite Transmitter
Yes - with red-eye reduction lamp
1/200sec
'+/- 2EV in 1/2 or 1/3 increments
Yes, with compatible External Flash
Yes
Yes
Yes/ No
E-TTL II with EX series Speedlites, wireless multi-flash support
via camera menu screen
Scene Intelligent Auto (Stills and Movie), No Flash, Creative Auto, Portrait, Landscape, Close-up, Sports, SCN(Kids, Food, Candlelight, Night Portrait, Handheld Night Scene, HDR Backlight Control), Program AE, Shutter priority AE, Aperture priority AE, Manual (Stills and Movie)
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3)
sRGB and Adobe RGB
Highlight Tone Priority
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings)
Multi Shot Noise Reduction
Auto Correction of Lens Peripheral illumination and Chromatic aberration correction
Basic+ (Shoot by ambience selection, Shoot by lighting or scene type)
Creative filters (Art Bold, Water painting, Grainy B/W, Soft focus, Toy camera effect, Miniature effect, Fish-eye)
Resize to M or S1, S2, S3
Single, Continuous, Self timer (2s, 10s+remote, 10s + continuous shots 2-10)
Max. Approx. 5fps. for approx. (speed maintained for approx. 940 images (JPEG)¹, 8 images (RAW))²
Electronic viewfinder with image sensor
Approx. 100% vertically and approx.100% horizontally
29.97 fps
Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Hybrid CMOS AF III (Face detection and Tracking AF, FlexiZone-Multi, FlexiZone-Single)
One-shot AF and Servo AF selectable for Stills and Movie
Real-time evaluative metering with image sensor.
Evaluative metering (315 zone), partial metering (10% of the Live View screen), spot metering (2.7% of the Live View screen), center-weighted average metering.
Grid overlay (x2), Histogram, Multi aspect ratios
JPEG: Fine, Normal (Exif 2.30 compliant) / Design rule for Camera File system (2.0),
RAW: RAW (14bit, Canon original RAW 2nd edition),
Digital Print Order Format [DPOF] Version 1.1 compliant
Yes (RAW + Large JPEG only)
JPEG 3:2: (L) 6000x4000, (M) 3984x2656, (S1) 2976x1984, (S2) 1920x1280, (S3) 720x480
JPEG 4:3: (L) 5328x4000, (M) 3552x2664, (S1) 2656x1992, (S2) 1696x1280, (S3) 640x480
JPEG 16:9: (L) 6000x3368, (M) 3984x2240, (S1) 2976x1680 (S2) 1920x1080, (S3) 720x480
JPEG 1:1: (L) 4000x4000, (M) 2656x2656, (S1) 1984x1984, (S2) 1280x1280, (S3) 480x480
RAW: (RAW) 6000x4000
New folders can be manually created and selected
(1) Consecutive numbering
(2) Auto reset
(3) Manual reset
MP4 (Video: H.264 (standard or lightweight: IPB), Sound: AAC, recording level can be manually adjusted by user). Movie Digital zoom available while shooting
1920 x 1080 (29.97, 25, 23.98 fps)
1280 x 720 (59.94, 50, 29.97 fps)
640 x 480 (29.97, 25 fps)
HDR Movie (29.97fps, 25fps, 1280 x 720)
Max duration 29min 59sec, Max file size 4GB (If file size exceeds 4GB a new file will be created automatically)
14 Custom Functions
User copyright information (can be set in camera)
Image rating (0-5 stars)
Yes / Yes
Yes
1.5x - 10x enabled in 15steps
(1) Single image with information (2 levels)
(2) Single image
(3) 4 image index
(4) 9 image index
(5) 36 image index
(6) 100 image index
(7) Jump display
Image selection: All images, by Date, Folder, Movies, Stills, Rating
Playback time: 1/2/3/5/10/20 seconds
Repeat: On/Off
Background music: On/Off
Transition effect: Off, Slide in 1, Slide in 2, Fade 1, Fade 2, Fade 3
Brightness: Yes
RGB: Yes
Yes
Erase: Single image, All images in folder, Checkmarked images, unprotected images
Protection: Single image, all images in folder, all images on card
(1) Shooting menu (x4)
(2) Playback menu (x2)
(3) Setup menu (x3)
(4) Custom Functions menu
(5) My Menu
25 Languages
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean and Japanese
Update possible by the user.
Hi-Speed USB
Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (HDMI-CEC compatible), External microphone (3.5mm Stereo mini jack)
Canon Compact Photo Printers and PIXMA Printers supporting PictBridge
Yes
SD, SDHC or SDXC (UHS-I)card
Windows 8.1 / 8 / 7 SP1
OS X v10.8-10.10
Digital Photo Professional
EOS Utility, Picture Style Editor
1 x Rechargeable Li-ion Battery LP-E17
Approx. 440 (at 23°C, AE 50%, FE 50%)¹
Approx. 400 (at 0°C, AE 50%, FE 50%)
4 levels
Power turns off after 30sec or 1, 2, 4, 8 or 15mins.
AC Adapter Kit ACK-E18, Battery charger LC-E17
Eyecup Ef,
Rubber Frame Ef,
E-series Dioptric Adjustment Lenses,
Eyepiece Extender EP-EX15II,
Angle Finder C
Compatible with Eye-Fi cards
Semi-Hard Case EH26-L, EH-27L
All EF and EF-S lenses
Canon Speedlites (90EX, 270EX II, 430EX II, 600EX, 600EX-RT, Macro-Ring-Lite, MR-14EX II, Macro Twin Lite MT-24EX, Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT)
BG-E18
Remote Switch RS-60E3, Remote Controller RC-6
Hand Strap E2, GPS Receiver GP-E2
Chassis: Aluminum alloy and polycarbonate resin with glass fiber
Exterior: Polycarbonate resin with glass fiber and special conductive fiber
0 – 40 °C, 85% or less humidity
Approx. 131.9 x 100.9 x 77.8 mm
Approx. 565g (CIPA testing standard, including battery and memory card)
*Recommended Exposure Index
All data is based on Canon standard testing methods except where indicated.
Subject to change without notice.
Wi-Fi use may be restricted in certain countries or regions. Wi-Fi support varies by device and region.
¹ with 50mm lens at infinity, -1m-1 dpt
¹ Large/Fine(Quality 8) resolution<br>² Quoted burst rate is based on tests using a UHS-I memory card, with Canon's testing conditions, ISO 100, Standard Picture Style. Maximum fps and buffer capacity may be reduced depending on the cameras settings and light level Speed can vary depending on the subject, memory card brand and capacity, image recording quality, ISO speed, drive mode, Picture Style, Custom functions etc.
¹ Based on the CIPA Standard and using the batteries and memory card format supplied with the camera, except where indicated
