VIDEO SYSTEM
Recording Formats
AVCHD/MP4
Simultaneous Recording Possible
Recording Medium
16GB built-in flash memory
SDXC / SDHC
Relay recording
Max Recording Time*
Variable total, depending on memory card size[¹]
Internal memory: AVCHD mode, 3hrs[²]
MP4 mode: 4hrs 20mins
64GB SDXC card (not supplied): AVCHD mode, 24hrs 30mins[²]
MP4 Mode, 34hrs 45mins
SENSOR
Type
1/4.85" CMOS
Total Pixels
3.28 megapixel
Effective Pixels: Movie
2.07 megapixels[¹²]
Effective Pixels: Still
2.07 megapixels (16:9)
Filter
Bayer pattern filter
LENS
Advanced Zoom
57x
Optical Zoom
32x
Digital Zoom
1140x
Focal Length
2.8mm - 89.6mm
35mm Equivalent Focal Length
32.5mm - 1853mm / (38.5mm-1232mm: Advanced zoom off)
Maximum Aperture
f1.8 - f4.5
APERTURE TYPE
Minimum focusing distance
10mm
Image Stabilizer
Optical Image Stabiliser: Intelligent IS with Advanced Dynamic Mode
Wide Attachment Included
Yes
Lens Cover
Integrated
IMAGE PROCESSOR
Image Processor
DIGIC DV 4
Face Detection Technology
Yes
SCREEN
Screen size
7.5cm (3.0") Touchscreen LCD, 100% view
Vari-Angle
Yes
Pixels
230,000 dots
Touchscreen
Yes - capacitive type touch panel
TOUCH TRACKING
Touch Focus
Yes
Manual adjustment
Brightness, backlight
WI-FI FUNCTION
NFC
Yes
Remote Control & Streaming
YES (monitor in/out of home)¹, Supports optional Pan Table CT-V1 accessory
Movie Uploader
YES¹
Playback via browser
YES¹
Media Server
YES
Web Service
YES
BABY MODE
Baby Mode
YES - register up to 3 children
EXTERNAL HDD STORAGE
Direct storage to external HDD
Yes
MINIMUM ILLUMINATION
Minimum Lux.
4 lux
Night Mode
Low Light (0.4 lux)
Auto Gain Control Limit Adjustment
No
FOCUS
Auto/Manual
Yes / Yes
Control
Auto: Face Detection AF, TV AF
Manual: Touchscreen LCD, Touch focus
Manual Focus Assist
Yes (Magnification)
CREATIVE FEATURES
Slow Motion Recording
1/2 speed
Fast Motion Recording
2x, 4x, 10x, 20x, 60x, 120x, 1200x
Fast Motion Conversion
Yes
VIDEO SNAPSHOT
Touch Decorations
Yes
STORY CREATOR
Cinema-Look Filters
Yes
AE MODE
Smart Auto
Yes (38 Scenes)
Program AE
Auto
M Mode: P, Scn, (Portrait, Sports, Snow, Beach, Sunset, Night, Low Light, Spotlight, Fireworks)
Cinema Mode: P
Baby Mode
BACKLIGHT COMPENSATION
Backlight Compensation
Yes (automatic or user control)
WHITE BALANCE
Type
TTL
Auto
Yes
Set/Preset
Daylight, Tungsten
SHUTTER SPEED
Maximum
1/2000sec
Slow
1/2sec
DIGITAL EFFECT
Fade
Auto Fade, Wipe
Effect
No
IMAGE QUALITY ADJUSTMENT
Image Effects
Standard, Highlight Priority
CUSTOM CONTROL
Custom Control
Yes (touch panel operations)
STILL IMAGE
Capture Image Size
1920x1080 (not cinema mode)
Simulaneous Photo Recording
Yes
Photo Button
Touchscreen LCD
SELF TIMER
Self Timer
10 sec
RECORDING MODE
Recording Format
MP4 and AVCHD
Recording Mode
Four AVCHD recording quality modes[¹²]
50P: 1920 x 1080, 28Mbps;
MXP 50i/PF25: 1920x1080, 24Mbps;
FXP 50i/PF25: 1920x1080, 17Mbps;
LP 50i/PF25: 1440x1080, 5Mbps
Four MP4 quality recording modes[¹²]
50p: 1920 x 1080, 35Mbps;
25p: 1920 x 1080, 24Mbps,
25p: 1920 x 1080, 17Mbps,
25p: 1280 x 720, 4Mbps
Progressive Shooting Mode
50p, 25p
Slow and Fast Motion Recording
Yes
MULTI DIRECTIONAL INVERTED
Video Snapshot
Yes
Pre REC
Yes
STILL IMAGE
Date
Yes
MEMORY CARD
Secure Digital Card
SD / SDHC / SDXC
Movie Recording
Yes
Internal Data Transfer
Yes, movie and stills (internal memory to card)
MICROPHONE TYPE
System
Dolby Digital 2ch
AC3 2ch
Audio Scene Select
Yes
Zoom Microphone
No
Manual Rec. Level Control
Yes
TERMINAL
Headphone
Yes
Microphone
No
USB
Yes (Mini-B, Hi-Speed USB - Output Only)
AV
Yes (output only)
Component
No
HDMI
YES (HDMI™ Mini Connector: output only)
Built-in Charger
Yes
Tripod Mount
Yes
SMART FEATURES
Framing Assist
Yes
Quick Start
Yes (using LCD screen)
File Lock
Yes
BATTERY PACK
Type
Lithium Ion
Intelligent Battery System
Yes
Battery Included in the Kit
BP-727
Max Recording Time (Included Battery)*
2hrs 55mins
DIMENSIONS
W x H x D
53 x 58 x 116
Weight
240g
Disclaimer
*: 4Mbps MP4 recording mode
Specifications are subject to change without notice
*: 4Mbps MP4 recording mode
Specifications are subject to change without notice
Footnote
¹ For both AVCHD and MP4, class 4 or higher-speed memory cards are recommended.
² When AVCHD/MP4 recording has continued for 12 hours, it will automatically stop and then start again automatically
¹ Advanced Zoom ON, 16:9 recording mode, wide end
² Image Stabiliser mode set to Standard or Off
¹ Requires installation of CameraAccess Plus app. Supported OS: iOS 7,iOS 8 iOS 9, Android / 4.0 / 4.1 /4.2/4.3/4.4/5.0/5.1 'Out of home' monitoring function requires UPnP WLAN router and global IP address. Functionality Not guaranteed on all devices
¹ Requires installation of MovieUploader app. Supported OS: iOS 6,iOS 7, iOS 8. Functionality Not guaranteed on all devices
¹ Supported OS: iOS5,iOS6,iOS7,iOS8 Android 2.3/ 3.2/ 4.0/ 4.1/ 4.2. Web browser must support HTML5. Functionality Not guaranteed on all devices
¹ For both AVCHD and MP4, class 4 or higher-speed memory cards are recommended.
² Variable bit rate used in all recording modes
¹ For both AVCHD and MP4, class 4 or higher-speed memory cards are recommended.
² When AVCHD/MP4 recording has continued for 12 hours, it will automatically stop and then start again automatically
¹ Advanced Zoom ON, 16:9 recording mode, wide end
² Image Stabiliser mode set to Standard or Off
¹ Requires installation of CameraAccess Plus app. Supported OS: iOS 7,iOS 8 iOS 9, Android / 4.0 / 4.1 /4.2/4.3/4.4/5.0/5.1 'Out of home' monitoring function requires UPnP WLAN router and global IP address. Functionality Not guaranteed on all devices
¹ Requires installation of MovieUploader app. Supported OS: iOS 6,iOS 7, iOS 8. Functionality Not guaranteed on all devices
¹ Supported OS: iOS5,iOS6,iOS7,iOS8 Android 2.3/ 3.2/ 4.0/ 4.1/ 4.2. Web browser must support HTML5. Functionality Not guaranteed on all devices
¹ For both AVCHD and MP4, class 4 or higher-speed memory cards are recommended.
² Variable bit rate used in all recording modes
