Canon XC10 Specifications

CAMERA

Sensor

1-Inch CMOS

System

Bayer pattern filter

Total pixels per sensor

13.36MP

Effective pixels per sensor

Video Mode: 8.29MP (3840 x 2160); Stills mode: 12MP (4000 x 3000)

Minimum illumination

AUTO MODE: PAL


50.00i: Approx. 5.32 lux (at 1/50 sec. shutter speed)


25.00P: Approx. 2.68 lux (at 1/25 sec. shutter speed)


Manual Mode, PAL


50.00i/25.00P: Approx. 0.05 lux (shutter speed 1/2 sec.)

Horizontal Resolution

1600 lines or more (4K Recording), 800 or more (Full HD recording)

Zoom ratio

10x

Focal length

Video Mode: 8.9 - 89mm (27.3-273mm 35mm equivalent)


Stills Mode: 4:3 - 24.1 -241mm,/ 3:2 - 25 - 250mm, /16:9 - 27.3 - 273mm (approx.)

Minimum focus distance

50cm across entire zoom range; approx. 8cm at wide macro setting

ND filter

Yes, single density built-in. 1/8 (3-step) equivalent

Zoom control

Manual. 35mm conversion markers provided

Focus control

AF, Face detection and tracking, Push AF, AiAF (Photo Mode) Manual focus ring


Touch Focus Function.

Iris control

Auto, manual via control wheel

Aperture range

f/2.8 - f/5.6 (W-T)

Filter diameter

58mm

Lens elements/groups

12 Groups of 14 elements

Aperture blades

8 blade diaphragm. Mechanical shutter built in.

Image stabilization system

Optical (lens shift) + electronic stabilisation.


Movie Mode IS options: Dynamic IS¹, Standard IS, Powered IS

Digital zoom

No Digital Zoom. 2 x Digital Teleconverter via assignable button

Type

DIGIC DV 5

Sampling accuracy

YCC 4:2:2

Bit depth

8-bit

RECORDING

Video storage media

4K: CFast 2.0™ card, VPG130 supported; Full HD/Photo: SD card (Class 10 recommended for 50Mbps)

Capacity

Depends on card used

Recording time

Depends on card capacity. 4K: CFast 2.0™ 64GB approx. 25 min @305Mbps.


Full HD 64GB SD card approx. 170 min @50Mbps

Recording file format

Material eXchange Format (MXF)

Recording format

Video Format: XF-AVC. Compression Format: MPEG-4 AVC/H.264

Recording frame rate (PAL model)

4K Recording: 305Mbps/205Mbps at 25.00P


Full HD Recording: 50Mbps at 50.00P; 35Mbps at 50.00i/25.00P

Slow/Fast motion

Yes: 1/4x - 1200x speed¹. Frame rate is 25.00P

Interval Record

Yes, Photo Mode only

Frame Record

No.

Pre Record (cache record)

Yes, in Full HD mode to SD card only. 5 Second pre-record time

Scan Reverse

No

HD->SD conversion

No

Internal Data Transfer

No

Photo storage media

SD card

Still Image quality

8.29 - 12Mp depending on format

SYSTEM

Monitoring Panel Type

Capacitive touch screen LCD

Size

3-Inch /7.66cm

Dots

approx. 1,030,000

Image quality adjustments

Brightness, Backlight

Adjustable

Yes. 2-axis parallel hinge mechanism

Waveform Monitor

No

Focus Assist

Magnification. Area selectable via touch screen

Peaking

Yes, Red, blue or yellow selectable

Zebra

Yes. 70% or 100%, selectable

Markers

Yes. Horizontal or grid markers white or grey

Size

No EVF. Optical loupe viewfinder attachment for LCD screen supplied

Audio in

Built-in stereo microphone, 3.5mm stereo mini jack external microphone

Headphone output

3.5mm Stereo mini jack

Video monitor output

No

HDMI

Yes. Output only

HDMI Video Output (Recording Mode)

Colour Bars (HD output only)


Camera Mode: (Dependent on capabilities of external recording device)


305Mps/205Mbps: 3840x2160 (25.00P)


1920x1080 (50.00P/50.00i) 720 x 576: 50.00P


50 Mbps: 1920 x 1080 (50.00P/50.00i) 720 x 576: 50.00P


35 Mbps: 1920 x 1080 (50.00P/50.00i) 720 x 576: 50.00P

HDMI Video Output (Playback Mode)

PAL


4K movie playback : 3840x2160/25.00P: 1920x1080/50.00P/50.00i


720x576/50.00P


HD movie playback: 1920x1080/50.00P/50.00i


720x576/50.00P

USB

Yes mini-B, Hi-speed, Output only

HD/SD-SDI output

No

Time code

Yes, via HDMI

Genlock

No

Component out

No

AV terminal

No

DC input

Yes

Remote Control Terminal

No

Colour Bars

Yes. PAL Model: EB/SMPTE. Can be output via HDMI

Tally lamp

Yes

Accessory shoe

Yes, Hotshoe with synch contact for Canon Speedlite

Custom key

No

Custom Dial

No

SHOOTING FUNCTIONS

Exposure metering

Movie mode: Standard, spotlight, backlight


Photo mode: Evaluative, centre-weighted, spot

Exposure compensation

-2.0 - +2.0 stops in 1/3 stop increments (photos) and 1/4 stop increments (movies)

Auto Exposure mode

AUTO/Programmed AE (P)/Shutter-priority AE (Tv)/Aperture-priority (Av) / SCN (Portrait /Sports /Night Scene /Snow /Beach /Sunset /Low Light / Spotlight / Fireworks)

Exposure Lock

Yes (in compatible modes)

Auto Gain Control setting

Yes

Auto Gain Control limit

28.5dB

ISO Sensitivity

Movie /Photo: ISO 160 - 20000


Movie Mode with Canon Log or Wide DR selected: 500 to 20000

Gain setting

0.0 - 42.0dB


At the fine gain setting: Any setting in a 0.5 increment between 0.0 dB and 42.0 dB


Movie Mode with Canon Log or Wide DR selected: 9.0 dB (8.5 dB at fine gain setting) to 42.0 dB

SHUTTER SPEED

Control Modes

Manual, Shutter Priority AE (Tv), Auto Slow Shutter On/Off

Shutter speed

Movie Mode: 1/2, 1/3, 1/4, 1/5, 1/6 to 1/2000 sec. (in 1/4-step increments)


Photo Mode: 0.5 sec., 0.4 sec., 0.3 sec., 1/4 - 1/2000 sec. (in 1/3-step increments)

Shutter Angle

No

Slow Shutter (SLS)

Yes

Clear Scan

No

Infrared shooting mode

No

Built-in IR lamp

No

Wireless LAN standards

IEEE 802.11b/g/n (2.4GHz band) / IEEE 802.11a/n (5GHz band* )


*5GHz band not available in Qatar

Supported Wi-Fi Functions

Photo Mode: Playback (in browser) from SD card; Download and save images to user terminal device via web browser.

Supported Browser for Remote Operation

Internet Explorer, Safari (iOS), Safari (Mac OS),


Android standard browser

Remote Operation Control Features

Aperture, Focus, WB, Shutter Speed, ISO/Gain, Shooting Mode, Start/Stop Recording

Live view image Resolution

Camera setting mode: 680 x 383; Simplified setting: 284 x 160

Authentication Systems

Open/WPA-PSK/WPA2-PSK

Encryption

WEP64, WEP128, TKIP, AES

GPS Information (Optional Accessory)

Latitude/Longitude/Elevation, Coordinated Universal Time (UTC)

Auto

YES

Preset

6 Presets: Daylight, Shade, Cloudy, Tungsten (incandescent lamps or halogen bulbs), Fluorescent H (3-wavelength type fluorescent), Fluorescent (white fluorescent)

Shockless WB

Yes

Manual setting

Set 1, Set 2 (Default 5,500K)

Countup system

Regen/Rec Run/Free Run/Preset (Non-Drop Frame)

Start value setting

00:00:00:00, Set/Reset selectable

Recording

Linear PCM (2ch, 16 bit, 48 kHz)

Audio Scene (Movies)

Standard/Music/Festivals/Speech/Meetings/Forest


and Birds/Noise Suppression/Custom Setting*


(*) Custom setting cannot be selected in Auto mode.

Audio Settings (Movie Mode)

Built-in Mic Wind Screen: Auto High/Auto Low/Off


Internal mic attenuator: Auto / On / Off


Built-in Mic Frequency: Response: Normal, low-range boosting, low-range cutting,


mid-range boosting, low and high-range boosting


Built-in Mic Directionality: Monaural / Normal / Wide / Zoom: MIC Att. Auto / On / Off : MIC Low Cut. On/Off: Audio limiter, On/Off: Audio compressor: High/Low/Off

ACCESSORIES

Supplied

Lens hood, (Loupe) Viewfinder Unit, Remote Controller (RC-6), Battery Pack LP-E6N, High Speed HDMI Cable (HTC100/S), Compact Power unit CA-570, AC Cable, Interface Cable (IFC-300PCU/S), Shoulder Strap

Optional

Canon Battery Charger LC-E6/LC-E6E


GPS receiver GP-E2,


Canon Speedlites (270EX II, 320EX (with video light), 430EX II, 580EX II, 600EX-RT) - 2nd curtain synchronisation and wireless functions not supported,


Canon PROTECT Filter 58 mm, Canon ND4-L Filter 58 mm, Canon ND8-L Filter 58 mm

Battery Type

LP-E6N Battery Pack

Power Consumption

Approx. Max. Recording: 6.0W²/Playback: 4.1W

Continuous Recording Time

Approx.: 110 mins (maximum) / 75 mins(typical)³

MISCELLANEOUS

Dimensions

Approx. 125x102x122mm (body only)


Approx. 131x115x238mm (with viewfinder unit and lens hood)

Weight (camera only)

Approx. 930g

Weight (fully equipped)

Approx. 1040g (with lens hood, battery, CFast 2.0™ card and SD card)

Operating Temperature range

Approx. 0°C to 40°C, 85% (relative humidity)


Approx. -5°C to 45°C, 60% (relative humidity)

Disclaimer

Specifications are given for PAL version of the camera. NTSC version available in appropriate regions

Canon is an authorized licensee of the CFast 2.0™ trademark, which may be registered in various jurisdictions

All specifications are subject to change without notice

Footnote

¹ Dynamic IS not possible when recording in 4K or using Slow & Fast Motion mode

¹ Dynamic IS not possible when recording in 4K or using Slow & Fast Motion mode

¹ In 4K rec. mode 1/4 x and 1/2 x speed not possible to CFast 2.0 ™ card. In Full HD to SD card, 1/4 x rec is 1280 x 720.

¹ Recording time to CFast 2.0™ card. 305Mbps, at 25.00P, PAL mode
